National Instruments Design Suite V14.0 (Electronic Circuits Design)

National Instruments Corporation, the provider of platform-based systems that enable engineers and scientists to solve the world's greatest engineering challenges, announced the release of Circuit Design Suite 14.0, is a suite that can be effectively used for the circuit designing.

The NI Circuit Design Suite combines NI Multisim and Ultiboard software for a complete circuit design, simulation, validation, and layout platform.

Multisim is an intuitive environment for circuit design. With advanced mixed-mode simulation and validation, this software offers professional tools for your research and prototyping. And using a comprehensive library of components, you can easily build and validate circuit behavior.



Ultiboard is a flexible PCB layout and routing environment. Easily transfer completed Multisim schematics to Ultiboard and layout, route, and export completed designs for fabrication.

NI Circuit Design Suite 14.0
About National Instruments

Since 1976, National Instruments has equipped engineers and scientists with tools that accelerate productivity, innovation and discovery. NI’s graphical system design approach to engineering provides an integrated software and hardware platform that speeds the development of any system needing measurement and control. The company’s long-term vision and focus on improving society through its technology supports the success of its customers, employees, suppliers and shareholders.

Cadence Allegro And OrCAD (Including ADW) Version 17.00.00

Cadence Design Systems, Inc., a leader in global electronic design innovation, launched the Cadence Allegro and OrCAD 17.0 design solution with new features, enhanced customization capabilities, and simulation performance improvements that provide customers a shorter, more predictable path to product creation.

17.0, as with all major dot zero releases, contains a number of architectural changes that will have an adoption overhead for customers, such as 64Bit only operating system, database changes that require a database update and a new library padstack structure. Through discussions with customers around the world we have learned that a 2015 mandatory update to 17.0 may require more preparation at some customer sites. Therefore the OrCAD and Allegro management team have decided to create and release a new feature packed 2015 version of 16.6 (16.6-2015) that will deliver new OrCAD and Allegro products as well as new functionality tiering of the OrCAD and Allegro base PCB products and pull forward some of the key 17.0 features such as Shape Edit application mode. This new 16.6-2015 release is being planned for June’2015. Therefore 17.0 is being re-positioned as a limited access Early Adopter Program (EAP) release, available and supported for production work for those companies using Allegro who want/need to move to a 64Bit operating system and/or begin to take advantage of the new database Padstack support. With the new feature-rich 16.6-2015 release we do not expect a large number of customers will want to upgrade to 17.0.

About Cadence Design Systems, Inc.

Cadence enables global electronic design innovation and plays an essential role in the creation of today’s integrated circuits and electronics. Customers use Cadence software, hardware, IP, and services to design and verify advanced semiconductors, consumer electronics, networking and telecommunications equipment, and computer systems. The company is headquartered in San Jose, Calif., with sales offices, design centers, and research facilities around the world to serve the global electronics industry.

Name: Cadence Allegro and OrCAD (Including ADW)
Version: (64bit) 17.00.000
Home: www.cadence.com
Interface: english
OS: Windows 7even / 8 (All service packs, such as Windows 8.1)



Altium Designer 15.0.15 (2015)

Altium Limited, a global leader in Electronic Design Automation, native 3D PCB design systems (Altium Designer) and embedded software development toolkits (TASKING), announced the release of its professional printed circuit board (PCB) and electronic system level design software, Altium Designer 15.

Altium Designer 15 demonstrates the continuing commitment by Altium to produce software and solutions that increase productivity and reduce user stress during challenging electronics design projects. It reflects Altium’s commitment to supporting customer success by delivering products that customers both want and need. In keeping with these objectives, Altium Designer 15 includes powerful new enhancements for designing the next generation of high-speed printed circuit boards, and keeping up with the leading trends in industry with support for new fabrication output standards.

High Speed Signal Pin Pairs

Modern designs require signal propagation at rates up to 100 gigabits per second. Designing to these specifications in previous generation design software is challenging. This process traditionally required manual rework and careful signal planning outside of the design tool, typically in a spreadsheet program – causing additional steps and introducing lots of room for errors. With Altium Designer 15 a new Pin Pairs feature has been added to:

- Enable accurate length and phase tuning across termination components.
- Enable length, phase and delay tuning traversing an entire signal path.

Designers will no longer require external software or have to maintain complex lists of signals and nets, but instead will be able to plan and route groups of high speed nets with much greater efficiency and accuracy.

IPC-2581 and Gerber X2 Support

As a Computer Aided Manufacturing format, traditional Gerber has its origins in standard RS-274D published almost 35 years ago; many consider “standard Gerber” to be out of date. Ucamco have recently updated RS-274X to Gerber X2 to incorporate critical fabrication data previously missing, and the International Printed Circuit association has developed an entirely new standard, IPC-2581. Both resolve issues of ambiguous or missing data encountered when using older formats such as Gerber RS-274X to hand off design to fabrication, completely describing a PCB according to its design:

- Copper layer images.
- Plated and unplated holes, slots, routes, grooves and microvias.
- PCB design outline and cutout regions.
- Complex layer stack regions.
- Rigid and flexible board areas.
- Material specifications.
- Fabrication notes, tolerances, and other critical standards-compliance information.

Altium Designer 15 introduces support for both IPC-2581 and Gerber X2, keeping designers up to date while giving them a choice that broadens their selection of PCB fabrication partners.

Along with additional new features and ongoing maintenance based on solid customer feedback, Altium Designer 15 will enhance electronics engineering workflow and reduce communication bottlenecks between designers and manufacturers.

About Altium Ltd.

Altium Limited is an Australian multinational software corporation that focuses on 3D PCB design, electronics design and embedded system development software.

Altium Designer, a unified electronics design environment links all aspects of smart systems design in a single application that is priced as affordable as possible. With this unique range of technologies Altium enables electronics designers to innovate, harness the latest devices and technologies, manage their projects across broad design ‘ecosystems’, and create connected, intelligent products.

Name: Altium Designer
Version: 15.0.15 build 41991
